| Size of The Loads ( Pallets) to be Wrapped | |
| Min paper roll size | 600mm (Dia.) X 600mm (Width) |
| Max paper roll size | 1800mm (Dia) X 2000mm (Width) |
| 2000kgs | |
| Film Delivery System | |
| Carriage | Power pre-stretch Film Delivery System, stretch ratio up to 300%. Help you save Packing cost= Save money!! Carriage door opens for effortless roll change and thread film Film tension adjustable |
| Machine Performance | |
| Packing efficiency | 50-60 rolls/hour |
| Load height sensing by photocell | YES |
| Wrap arm soft start & stop | YES |
| Wrap arm rotation speed: | 3-35 rpm adjustable |
| Wrap arm Zone ( rotating inner diameter) | 2300mm |
| Wrap arm drive | Slew bearing drive |
| Wrap Arm drive | SEW motor |
| Carriage Up/down Speed | Adjustable |
| Electrical Features | |
| Power supply voltage | 380 V 3 Phase - 50/60 Hz |
| Power | 2.5Kw |
| Machine weight & size | |
| Machine size | 4050mm (L) 2000mm (W) 2500mm (H) |
| Approximate Machine net weight | 1200kg (not include paper roll lifter unit) |
| Paper roll lift unit | |
| Roller length | 1800mm |
| Roller diameter | 200mm |
| Roller center distance | 450mm |
| Stretch Film Roll detail | |
| Film Max. external diameter (D): | 230 mm |
| Internal diameter (d): | 76 mm |
| Film width: | 500 mm (20'') |
| Film thickness: | 17-35 µm |
-
None
Our Stretch wrapping machines ensure your loads(pallets) are properly wrapped and safety shipped, reducing shipping damage in the supply chain.
