| Size of The Loads ( Pallets) to be Wrapped | |
| Min load size | 600mm (L) X 500mm (H) |
| Max load size | 1200mm (L) X 240mm (H) |
| Thickness | 18-50mm |
| Max load height | 2400mm (94'') (Option: 2800mm, 3000mm) |
| Max load weight | 2000kgs(4400lbs) (Option: 2500kgs, 3000kgs) |
| Film Delivery System | |
| Carriage | Power pre-stretch Film Delivery System, stretch ratio up to 300%. Help you save Packing cost= Save money!! Carriage door opens for effortless roll change and thread film Film tension adjustable |
| Machine Performance | |
| Packing efficiency | 20-40 loads / hour |
| Load height sensing by photocell | YES |
| Turntable soft start & stop | YES |
| Turntable rotation speed: | 3-12 rpm adjustable |
| Turntable diameter | 1650mm (65'') |
| Turntable height | 78mm |
| Move machine with forklift | Front & Rear |
| Carriage Up/down Speed | Adjustable |
| Electrical Features | |
| Power supply voltage | 220 V 1 Phase - 50/60 Hz |
| Power | 1.8Kw |
| Machine weight & size | |
| Machine size | 2675mm (L) 1650mm (W) 3280mm (H) (105'' L X 65''W X 112'H') |
| Approximate Machine net weight | 700kg |
| Stretch Film Roll detail | |
| Film Max. external diameter (D): | 230 mm |
| Internal diameter (d): | 76 mm |
| Film width: | 500 mm (20'') |
| Film thickness: | 17-35 µm |
AUTO FILM CUT-OFF
Cut film tail automatic after stretch wrapping cycle finished, save operator time
BIGGER TURNTABLE DIAMETER
Increase length and width of your loads: 1800mm; 2000mm
EXTEND PACKING HEIGHT
Increase the stretch wrapper wrap heights for your loads:2800mm ;3000mm; 3200mm
Our Stretch wrapping machines ensure your loads(pallets) are properly wrapped and safety shipped, reducing shipping damage in the supply chain.
