  • ST-5030LG High Grade Shrink Tunnel

ST-5030LG High Grade Shrink Tunnel

ST-5030LG uses advanced circulation technology and special manufacturing. The wind orientation can be adjusted and the shrink effect is good;

Product Details

    Model          ST-5030LG
    Power SupplyAC220/380V 3PH 50/60Hz
    Tunnel Size L×W×H1500×500×300mm
    Packing Speed0-15m/min
    Machine Size L×W×H1860×985×1315mm
    Packaging Size L×W×H1910×1035×1465mm
    Air Temperature0-300℃
    Table Height850±50mm
    G./N. Weight493/453kgs
    Shrink FilmPOF, PVC,PE

    ●The heating elements are stainless steel which has a long life span and high energy efficiency;

    ●The use of French Schneider inverter controls transmission speed which has the function of infinitive speed;

    ●Imported insulation curtain greatly reduces the heat loss;

    ●The shrink temperature, conveyor speed and air volume are adjustable;

    ●Visual window makes the shrinking process more clear;

    ●The conveyor uses new types of rollers covered with durable imported fiber tubes which have the functions of anti-high temperature, wear resistance, non-film damage, non-deforming and long terms using; The roller can choose rotating or non-rotating to meet different shrinking f different products.

    We can offer customized machine according to the size of your products!

    We can replace the configuration according to your needs!

    customized machine
