Size of the door/window/board to be Wrapped | |
Min load size | 600mm (L) X 500mm (H) |
Max load size | 1200mm (L) X 240mm (H) |
Thickness | 18-50mm |
Max load height | 1800mm (Option 2400mm, 2800mm) |
Machine Performance | |
Packing efficiency | 20-30 loads/hour |
Load height sensing by PE | YES |
Turntable soft start & stop | YES |
Turntable rotation speed: | 3-12 rpm adjustable |
Turntable diameter | 1650mm (Option: 1800mm, 2000mm,2200mm, 2400mm) |
Turntable height | 78mm |
Move the machine with forklift | Front & Rear |
Carriage Up/down Speed | Adjustable |
Film Delivery System | |
Carriage | l Power pre-stretch Film Delivery System, stretch ratio up to 250%. l Film tension adjustable |
Electrical Features | |
Power supply voltage | 220 V 1Phase – 50/60 Hz |
Power | 1.5Kw |
Machine Weight & Size | |
Machine size (LXWXH) | 2575mm X1650mm X2760mm |
Machine weight | N.W. 650KG G.W.750KG |
Top Platen Unit | |
Top platen drive | Motor drive |
Top platen speed | Up-down speed is adjustable |
Options available to custom build to meet specific needs
1. AUTO FILM CUT-OFF
Cut film tail automatic after stretch wrapping cycle finished, save operator time
2. BIGGER TURNTABLE DIAMETER
Increase length and width of your loads: 1800mm; 2000mm
